Eletric Pipe bending machine with square dies W-76B

Eletric Pipe bending machine with square dies W-76B

Add to Wishlist
Add to Wishlist

Main Features:

1. For making quick work of large radius bends and doing complete circles.

2. Especially applicable to the production of steel greenhouse frame.

3. Capable of rolling bending thin-walled mild steel, stainless steel round& square tubes.

4. Manual adjustment of top roll.

5. Two driving rollers and one driven roller.

6. Foot pedal with emergency stop available on request. This speciallydesigned section and tube rolling machine can be used  on either side front or rear of machine,the front is designed to handle the larger tube as the rear

7. is capable of rolling smaller tubes.


8. Toolings made of grey cast iron allows long service life.

Order on WhatsApp
Category:

Description

Description Unit 38CNC-2A-1S 50CNC-2A-1S 63CNC-2A-1S 76CNC-2A-1S
Max bending capacity mm 38*2 50*2 63*3 76*4
Max bending radius mm 20-200 20-250 25-300 30-350
Max mandrel length mm 3200 3500 4000 4200
Max bending degree Degree 190 190 190 190
Bending Speed 120°/s 90°/s 90°/s 90°/s
Rotary speed 360°/s 180°/s 120°/s 120°/s
Feeding speed mm/s 0-800 0-800 0-500 0-500
Feeding accuracy degree ± 0.1 ± 0.1 ± 0.1 ± 0.1
Rotary accuracy degree ± 0.1 ± 0.1 ± 0.1 ± 0.1
Bending accuracy degree ± 0.1 ± 0.1 ± 0.1 ± 0.1
Data input 1.Coordinate ( X, Y, Z )
2.Working value ( Y, B, C )
Control system       servo feeding, servo rotating, hydraulic bending
Max bending unit on the same pipe unit 20 20 20 20
Main Motor Power Kw 4 5.5 5.5 7.5
Feeding servo KW 1 1 1 1.5
Rotating servo KW 0.4 0.75 1 1
Max storage section 组 2000 2000 2000 2000
Oil tank L 320 320 320 400
System hydraulic pressure Mpa 16 16 16 16
Machine Size mm 4000*700*1300 4500*700*1300 5000*1200*1300 5600*1200*1300



  Description Unit 89CNC-2A-1S 114CNC-2A-1S 130CNC-2A-1S 168CNC-2A-1S 219CNC-2A-1S
Max bending capacity mm 89*6 114*8 130*10 168*12 219*16
Max bending radius mm 400 450 600 750 1000
Max mandrel length mm 4600 5000 5500 6500 7000
Max bending degree Degree 190 190 190 190 190
Bending Speed 60°/s 45°/s 30°/s 20°/s 15°/s
Rotary speed 120°/s 90°/s 90°/s 60°/s 45°/s
Feeding speed mm/s 0-500 0-500 0-500 0-400 0-400
Feeding accuracy degree ± 0.1 ± 0.1 ± 0.1 ± 0.1 ± 0.1
Rotary accuracy degree ± 0.1 ± 0.1 ± 0.1 ± 0.1 ± 0.1
Bending accuracy degree ± 0.1 ± 0.1 ± 0.1 ± 0.1 ± 0.1
Data input 1.Coordinate ( X, Y, Z )
2.Working value ( Y, B, C )
Control system         servo feeding, servo rotating, hydraulic bending
Max bending unit on the same pipe unit 16 16 16 16 16
Main Motor Power Kw 11 15 18.5 22 30
Oil tank L 700 900 1200 1200 1500
System hydraulic pressure Mpa 16 16 16 16 16
Machine Size mm 6000*1350*1400 6500*1350*1450 7000*1500*1600 7600*1580*1680 9000*1800*1750
